Company Overview: EVBox

EVBox is an Amsterdam headquartered, global electric car charge point manufacturer and charging management software company. EVBox was founded in 2010 with a clear vision: ‘a fully modular charging station that facilitates easy installation, maintenance upgrades, and above all, uncompromising quality and durability’. EVBox has a global footprint that few companies in the EV industry have achieved. The company has won a number of awards to include:

Leading provide of Public Charging Network and EV Charging Services: Navigant Research (2019).
CES Innovation Award (2019).
Red Dot Award (2019).

The company achievements to date include:

More than 250,000+ charging points powering EV drivers.
5,000+ DC fast charging points.
70+ countries.

Global EV Charging Portfolio: Overview

Overview
Residential EV chargers (AC):	Yes
Business EV chargers (AC):	Yes
Public EV Chargers (DC):	Yes
Untethered (socket only) EV chargers:	Yes
Tethered EV chargers:	Yes
Smart EV chargers:	Yes
Solar Compatible:	No
Warranty:	3 years (an extendable warranty available)
Available via e-zoomed:	Yes

Residential Charging

Home Charging
Product names:	EVBox Elvi
Smart:	Yes
Approved for grant:	Yes
Product range:	7.4kW to 22 kW (Tethered)/ 7.4kW to 22kW (Untethered)
Prices from (not including grant):	£950 (including VAT)

EVBox Elvi Home EV Charging Station

EVbox Elvi Home EV Charging point — **EVBox Residential EV Chargers Available Via e-zoomed (credit: EVBox)**

Key Features	Elvi Home EV Charging (7.4kW to 22kW- Tethered/ Untethered)
Model:	Elvi
Charging capacity:	Upgradable 7.4 –22 kW
Charge mode:	Mode 3 (IEC 61851-1)
Number of connectors:	1
Connector options:	Fixed cable or Type 2 Socket/Socket+Shutter
Fixed cable type:	Type 1 (SAE J1772) or Type 2 (IEC 62196-2) plug
Fixed cable length:	6 m (18 ft)
Connection capacity:	Selectable 1-phase or 3-phase, 230–400V, 16 A and 32 A, 50-60 Hz
Secondary power circuit:	12 VDC
Relays:	2 x 35 A, 2 P, 12 V coil current
Metering:	Optional 3-phase S-Bus MID-certified kWh meter in wall dock
Ground fault detection:	6 mA DC CCID
Housing fire ratings:	UL94-5VA, US-FMVSS / ISO 3795 passed, DIN 53438 F1/K1
Storage temperature:	-35°C to 60°C (-31°F to +140°F)
Operating temperature:	-25°C to +45°C (-13°F to +113°F)
Operating humidity:	Max. 95% non-condensing
Enclosure ratings:	IP55, IK10 (IEC 60529)
CE certified:	Yes
Compliance:	IEC 61851-1, IEC 61851-21-2, CE EMC EU/2014/30, CE Low voltage EU/2014/35, RED EU/2014/53
Authorization:	Autostart / Keyfob / RFID card – controller with RFID reader type Mifare 13.56 MHz
Status indication / HMI:	LED ring
WLAN communication – Hub:	Wi-Fi 2.4/5 GHz (IEEE 802.11 a/b/g, IEEE 802.11 d/e/i/h) / Bluetooth 4.0
Cellular communication – Hub:	4G LTE (EU) option
External serial communication:	RS485 interface for dynamic load balancing and solar integration (also scheduled charging if supported via the backend)
Housing:	Polycarbonate
Dimensions (WxHxD):	Fixed cable – 186 x 328 x 161 mm (7 x 13 x 6 in)/ With socket – 186 x 328 x 219 mm (7 x 13 x 8 in)
Weight:	3 kg (6.6 lbs) – 3-phase, 32 A station with socket/ 6 kg (13.2 lbs) – 1-phase, 16 A station with 6 m (18 ft) fixed cable/ 11 kg (24.2 lbs) – 3-phase, 32 A station with 6 m (18 ft) fixed cable
Mounting:	Wall or pole

Available via e-zoomed.

Business Charging

Business Charging
Product names:	EVBox BusinessLine/ EVBox Iqon
Smart:	Yes
Approved for OLEV grant:	N/A
Product range BusinessLine:	Up to 22kW (untethered and tethered)
Product range Iqon:	22kW (tethered)
Prices from (not including grant):	£2,035 (including VAT)

EVBox BusinessLine EV Charging Station

Key Features	BusinessLine EV Charger (Up to 22kW- Tethered/ Untethered)
Model:	BusinessLine
Maximum charging capacity:	Up to 22 kW per connector
Charge mode:	Mode 3 (IEC 61851)
Output power:	1-phase (32 A) or 3-phase (16 A or 32 A), 230V – 400V
Number of connectors:	1 or 2
Connector type:	Type 2 sockets (with shutter option)
Information status:	LED ring
Session activation:	RFID / QR code / Autostart
Electrical safety:	Integrated RCBO 16 A or 32 A / 30 mA AC leakage detection per outlet / CCID 6 mA DC leakage detection per outlet
Maximum cluster size:	10 double stations or 20 single stations (20 connectors)
Mobile connectivity – Hub:	4G LTE-FDD CAT1 (B1/3/7/8/20) / 3G WCDMA (Band 1/8) / GSM (900/1800 Mhz)
Connectivity – Hub:	Dual band Wi-Fi 2.4/5 GHz, Bluetooth 4.0 for configuration with the EVBox Connect app, GPS
Time synchronization – Hub:	GPS / Wi-Fi
Communication protocol – Hub:	OCPP 1.5 S / 1.6 S / 1.6 J
Enclosure rating:	IEC 60529 / IP55 / IK08
Collision detection:	Tilt sensor
Operating temperature:	-25°C to +50°C
Operating humidity:	Max. 95% RH, non-condensing
Safety and compliance:	CE certified, RED Directive 2014/53/EU, EMC Directive 2014/30/ EU, Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/ EU (as amended by 2015/863/EU), EN/IEC 61851-1 (2017), EN/ IEC 61851-21-2 (2018), EN/IEC 61000-32 (2014), EN/IEC 61000- 3-3 (2013), EN 301 489-1 V2.2.0, EN 301 489-3 V2.1.1, EN 301 489-17 V3.2.0, EN 301 489-52 V1.1.0, EN 301 908-1 V11.1.1, EN 301 511 V12.5.1, EN 300 330 V2.1.1, EN 300 328 V2.1.1, EN 301 893 V2.1.1, EN 300 220-1 V3.1.1, EN 300 220-2 V3.1.1
Metering:	S-Bus MID certified class B
Smart energy management:	Adjusting max. current, charging profiles, dynamic load balancing (via MAX protocol)
Dimensions, mm (H x W x D):	600 x 255 x 205 mm (single socket)/ 600 x 255 x 410 mm (double socket)
Weight:	10 kg excluding packaging (single connector)/ 12 kg excluding packaging (double connector)
Mounting:	Wall or pole
Housing:	Polycarbonate

Available via e-zoomed:

EVBox Iqon Business EV Charging Station

**EVBox Iqon Business EV Charger (credit: EVBox)**

Key Features	Iqon EV Charger (Up to 22kW – Tethered)
Model:	Iqon
Maximum charging capacity:	Up to 22 kW per cable
Charge mode:	Mode 3 (IEC 61851) / Level 2 (UL2594)
Output power (dual 32 A input):	2x 22 kW (3-phase, 400 V AC, 32 A per cable)
Dimensions, mm (W x H x D):	415 x 1894 x 275 mm with 50 mm removable base extension
Weight:	85 kg (excluding packaging)
Mounting:	Ground mount (free standing, wall-supported or back-to-back)
Housing:	Stainless steel, polycarbonate
Plastic materials:	ISO 3795 passed, DIN 53438 F1/K1
Connectors:	2x Type 2 (IEC 62196-2) cables
Charging cable length:	5.5 m with smart cable management system
Plug holders:	With docking sensor and locking mechanism
Display:	8” (20 cm) LCD IPS full color screen (768 x 1024 px) with capacitive touch, sunlight readable
Display languages:	English, Spanish, French, German
System lighting:	Day/night mode, adjustable LED rings, automatic system wake-up
Session activation:	RFID / QR code
Electrical safety:	Integrated RCBO 40 A / 30 mA AC leakage detection per outlet / CCID 6 mA DC leakage detection per outlet
Maximum cluster size:	10 dual chargers (20 connectors)
Mobile connectivity – Hub:	4G LTE-FDD CAT1 (B1/3/7/8/20) / 3G WCDMA (Band 1/8) / GSM (900/1800 Mhz)
Connectivity – Hub:	Dual band Wi-Fi 2.4/5 GHz, Bluetooth 4.0 for configuration with the EVBox Connect app, GPS
Time synchronization – Hub:	GPS / Wi-Fi
Communication protocol – Hub:	OCPP 1.5 S / 1.6 S / 1.6 J
Enclosure rating:	IEC 60529 / IP55 / IK10
Collision detection:	Tilt sensor
Operating temperature:	-30°C to +50°C
Operating humidity:	85% @ 50°C (non-condensing)
Storage temperature:	-40°C to +60°C
Safety and compliance:	IEC 61851-1 (2017), IEC 61851- 21-2 (2018), IEC 61000-3-2 (2014), IEC 61000-3-3 (2013), EN 301 489-1 V2.2.0, EN 301 489-3 V2.1.1, EN 301 489-17 V3.2.0, EN 301 489-52 V1.1.0, EN 301 908- 1 V11.1.1, EN 301 511 V12.5.1, EN 300 330 V2.1.1, EN 300 328 V2.1.1, EN 301 893 V2.1.1, EN 300 220-1 V3.1.1, EN 300 220- 2 V3.1.1, CE conformity, RoHS, REACH
Metering:	S-Bus MID certified class B
Smart energy management:	Adjusting max. current, charging profiles, dynamic load balancing (via MAX protocol)

EVBox also has a range of DC EV charging stations to include:

EVBox Troniq Modular.
EVBox Ultroniq.
EVBox Troniq 50.
