Please Note
- This offer includes only the hybrid inverter. The battery modules, the battery base, battery control unit (BMU), balance of systems have to be purchased separately. For clarifications and an installation quotation, please email shop@ezoomed.com
Flexible Application
- 80 V ~ 460 V wide battery voltage range
- Ideal for both retrofitting and new installations
- Built-in smart PID Zero function
Energy Independence
- Seamless transition to backup mode, for protection against power outages
- Fast Charging or discharging, enabling higher self-consumption results
- Built-in EMS with advanced customization
Smart Management
- Real time data (10 seconds refresh sample)
- 24/7 live online monitoring and with integrated display
- Online IV curve scan and diagnosis
User Friendly Setup
- Plug and play installation
- iSolarCloud monitoring available on App and Web
- Lightweight and compact, optimized for heat-dissipation
Input (DC)
- Recommended max. PV input power: 10700 Wp
- Max. PV input voltage: 600 V
- Min. PV input voltage / Startup input voltage: 40 V / 50 V
- Rated PV input voltage: 360 V
- MPP voltage range: 40 V – 560 V
- No. of independent MPP inputs: 2
- No. of PV strings per MPPT: 1 / 1
- Max. PV input current: 32 A (16 A / 16 A)
- Max. DC short-circuit current: 40 A (20 A / 20 A)
- Max. current for input connector: 20 A
Battery data
- Battery type: Li-ion battery
- Battery voltage: 80 V – 460 V
- Max charge / discharge current: 30 A / 30 A
- Max charge / discharge power: 6600 W
Input / output (AC)
- Max. AC power from grid: 10700 VA
- Rated AC output power: 3680 W
- Max. AC output apparent power: 3680 VA
- Max. AC output current: 16 A
- Rated AC voltage: 220 V / 230 V / 240 V
- AC voltage range: 154 V – 276 V
- Rated grid frequency: 50 Hz / 60 Hz
- Grid frequency range: 45 Hz – 55 Hz / 55 Hz – 65 Hz
- Harmonic (THD): <3 % ( of rated power )
- Power factor at Rated power / Adjustable power factor: >0.99 at default value at rated power
- Feed-in phases / connection phases: 1 / 1
